Interchangeable Lenses, Complete RGB Color Control, and Battery or AC Power
The
ARRI Orbiter LED Light is part of a tunable light system with a powerful color engine and versatile, changeable optics. ARRI's 190-LED Spectra system features a wide range of color features allowing you to create an enormous range of colors with its six-color light engine, The light runs on universal 100 to 260V but it will also run on 48V batteries when AC power is unavailable.
Changeable optics
Changeable optics is the core innovation in Orbiter. With a wide variety of optics to choose from, Orbiter transforms into the perfect light for your application without sacrificing beam, output, or color quality. The Quick Lighting Mount (QLM) in Orbiter allows for optics with vastly different properties to be attached to the fixture. The high-output, directional beam of the open face optic is ideal for throwing light long distances. The high precision of the projection optics creates a perfect circle of light that can be shaped with cutters, focus, and gobos. The dome optic provides omnidirectional, soft light, great for illuminating large spaces, and a universal QLM adapter creates a direct mounting point for Orbiter-specific Chimera and DoPchoice products. With versatility built in, there is great potential for creating additional optics for different applications.
Orbiter featuring a 60° open face optic
ARRI Spectra six-color LED light engine
Orbiter is an extremely bright and powerful, directional LED fixture with an output similar to that of the corresponding HMI systems. Its new high output, yet tunable, ARRI Spectra light engine can create hard shadows with defined edges.
Including a red, green, blue, amber, cyan, and lime LED, the ARRI Spectra six-color light engine translates into a wider color gamut, more accurate colors, and most importantly, higher color rendition across the entire CCT range. Skin tones look amazing and natural, and hues are precisely reproduced. Orbiter has a larger CCT range of 2,000 to 20,000 K with ultra-high color rendition across all color temperatures. Using a combination of three dimming techniques, Orbiter’s cutting-edge electronics provide smooth dimming down to zero without color changes or jumps.
LiOS – The new Lighting Operating System
Orbiter is able to take advantage of more than five years of software development for the SkyPanel. Its new software called LiOS (Lighting Operating System) includes all the innovative and groundbreaking features of the SkyPanel plus others, making Orbiter one of the most fully-featured luminaires on the market. LiOS’s eight-color modes include CCT, HSI, individual color, x/y coordinates, gel and source matching, lighting effects, and the new color sensor mode that measures ambient light and recreates it through Orbiter’s output. Other new features in LiOS include simplified DMX modes, performance-enhancing operational modes, over 240 slots for favorites to be stored, optics recognition, multi-language support, a custom boot screen, and many more still to come.
Removeable control panel
With a 4” full-color display, quick navigation buttons, and integrated sensors, the Orbiter control panel allows for easy use with a graphic user interface. Simplified menu structure and re-imagined user interfaces provide one-glance operational views and uncluttered screens. This intuiive design makes changing the color or finding a setting easier than ever before. In addition, the control panel is removable and can be used handheld with the aid of a 5 or 15 m (16.4 or 49.2 ft) control panel cable.
Enhanced connectivity
Including a full suite of input and output connectors, Orbiter is prepared for digital communication—today and tomorrow. Ethernet daisy chaining is now possible with two EtherCON ports supporting Art-Net 4, sACN, and TCP/IP. Two USB-A ports are used for LiOS updates and connection of third-party peripherals such as Wi-Fi USB dongles. LumenRadio’s CRMX solution is included, allowing for wireless DMX. Two 5-pin XLR DMX ports used for conventional DMX & RDM communication in and through, and a 3-pin XLR DC input for 48 V power station. An SD Card slot enables future expansion of the software. Finally, a USB-C port is available for computer communication and servicing.
Full suite of sensors
Included in Orbiter is a color sensor for measuring the ambient light, a 3-axis accelerometer and magnetometer for sensing the pan, tilt, roll, and heading of the fixture, heat sensors for keeping the LEDs and electronics at exactly the right temperature, and an ambient light sensor for automatically dimming the control panel display. All these sensors make for a better user experience and increased control over the fixture. Available data improve workflow also in postproduction and service.
Robust, weatherproof housing
The outer design of Orbiter meets the demands of heavy, daily usage. A new weatherproof housing enables outdoor application by using an aluminum cast body with bumpers made of reinforced plastic. The handle makes transport comfortable and allows for handheld operation due to perfect balance.
Large range of applications
Orbiter's wide range of optics and features allows the fixture to be used in a great variety of applications without compromising quality. Markets such as film and television production, broadcast, theater and live entertainment, and even still photography are just some examples of environments where Orbiter excels. The fixture’s ability to throw light long distances with its open face or projection optics, while at the same time being able to serve as a soft light, brings the flexibility needed on today’s fast-paced film sets. Orbiter’s projection optic will enable broadcasters to have controlled, high-quality light in the studio, and with its battery power, Orbiter can easily be used on the move. The projection optic is the key feature for the theater and live entertainment market and Orbiter also exceeds expectations for continuous lighting in still photography. All in all, Orbiter’s software innovations and connectivity make it the ultimate companion for dynamic lighting setups.
Included:
ARRI Orbiter LED Light with Open Face without Lens, Yoke & Cable (Blue/Silver)
Not in box:
Yoke
Power cable
Control Panel
ARRI Orbiter Specs
Light Fixture
Color Temperature |
2000 to 20,000K |
Color Modes |
Full RGB Tuning |
Color Accuracy Standard |
CRI 98
TLCI 95 |
Dimming |
Yes, 0 to 100% (Continuous) |
Display |
LCD |
Housing Material |
Aluminum |
Number of LEDs |
190 (RGB) |
Expected Lamp Life |
50000 Hours (L70) |
Connectors
Power Input Connector |
3-Pin XLR, powerCON |
DMX Connector |
5-Pin XLR, RJ45 |
Service Connector |
USB Type-A |
Lens
Mounting
Yoke Mount |
ARRI Quick Release |
Remote Operation
Remote Control Type |
DMX, Wired Remote |
Power
AC Input Power |
100 to 260 VAC, 50 / 60 Hz |
Power Source |
AC Adapter, External Battery |
Max Power Consumption |
500 W |
Power Pass-Thru |
Yes |
Cable
Physical
Operating Temperature |
-4 to 113°F / -20 to 45°C |
Protection Class |
I |
