With power that positions it between the M40 and the ARRIMAX 18/12, the M90 HMI Lamp Head from ARRI employs faceted MAX Reflector Technology that focuses from 15 to 49 degrees, combining the best qualities of a Fresnel and PAR fixture to produce an output similar to a 12,000W light from a 9,000W lamp.The IP23 weather-resistant M90 ships with a yoke with a 1-1/8" Junior mounting pin. Tilt lock levers on both sides of the light firmly secure the weighty 88 lb fixture.
The M90 requires a ballast for use and 2 are available. Both units employ CCL (Compensation of Cable Losses) to maintain power with long cable runs independent of their length. They also feature a power-saving Active Line Filter (ALF) and built-in DMX for remote operation from a console. The standard EB 6/9 operates at 50, 60 and 75 Hz while the 1000 Hz high speed version allows up to 1,000 flicker-free frames per second.
- 5-Year extended warranty
- Light output nearly matches a 12K PAR (with lens)
- As small and lightweight as a 6K PAR
- Can also be used with 6,000W (120V nominal) lamps and ballasts
- Tilt locks on both sides support heavy accessories
- Easy maintenance
- Weather resistant IP23
- Suitable for high frame rate images
